Ortur Laser Master 2 S2 Support

related downloads

All downloads related to OLM2 S2

1. User Manual

The user manual is an instruction manual that describes the functions, installation and use of the laser engraving machine in detail, allowing users to understand how to use the machine.

2. Laser Module User Manual

3. Software Guide

Software Guide

The software guide is to be compatible with more operating systems and devices. Here you can download the software, learn the operation, and obtain parameters.



  • LightBurn
  1. Support OS:Windows、Mac OS、Linux
  2. Support Machines:All Ortur laser engraving machines
  3. Download Link:LightBurn Download link
  • LaserGRBL
    1. Support OS:Windows from XP to Win 11
    2. Support Machines:All Ortur laser engraving machines
    3. Download Link:LaserGRBL Download link

4. Firmware Release

In some circumstances, a firmware update is required to improve the Ortur machine performance or fix discovered issues. In some less common situations, a firmware upgrade might be required to clear issues caused by user error.

  • ESP_OLM2S2_191_230313
  1. Release Date: 13 March 2023
  2. Version: V1.91
  3. Update information:
    • Fixed the bug that printing in G20 imperial units appeared skewed
    • Problem:
      When using G20 (inch unit) in LightBurn, there is an image tilt phenomenon
      In motion control, it will check whether the movement of the equipment exceeds the stroke. In
      order to solve the limit alarm problem caused by the cumulative error of the floating point number
      in the G91 (relative value coordinate calculation) mode, the rounding algorithm is used in the limit
      algorithm. Use The precision of the floating point number of the coordinate value of G20 is 0.0001,
      The coordinate value floating point precision of G21 is 0.001, and the coordinate value precision of
      G20 is lost due to the rounding algorithm.
      Solution: Rounding Algorithms Add one digit (total 4) of precision.
    • Fix M7/M8 problem where Lightburn Air Assist command will turn off Enclosure Fan.
  4. Note: Oficial Release version
  5. Download Link: ESP_OLM2S2_191_230313.zip
  • Specifications

  • Product Promotion

  • Tutorial videos

  • Support Videos

  • Finished video

Product

OLM2 S2

Product Material

Acrylic+Auminum

Product DIM.

580*550*150mm

Package DIM.

620*230*130mm

N.W.

2,400g

G.W.

3,650g/4,000g

Shipping Method

Not pre-assembled

Product Feature

Portable

The photoelectric power is related to the laser module supporting the machine.

LU2-2A   Peak Power: 48w
Optical Power: 2.1w
AC/DC Output: 24V 2A

LU2-4SF   Peak Power: 48w
Optical Power: 5.5w
AC/DC Output: 24V 2A

LU2-4LF   Peak Power: 48w
Optical Power: 5.5w
AC/DC Output: 24V 2A

LU2-10A   Peak Power: 72w
Optical Power: 10w
AC/DC Output: 24V 2A(2PCS)

Motor

Step Motor Nema 17 (X29/Y38mm)

Working Speed

5,000mm/min

Working Area

LU3-5 :X400*Y400mm
LU2-10B:X400*Y400mm
LU3-20B:X400 Y380mm

Extension Area(Optional)

X390*Y800mm(2.1w,5.5w)
X390*Y790mm(10w)

Mainboard

OLM-ESP-PRO-V1.2A

Support Function

USB

Security Function

1. Active Position Protection
2. Tilting Position Protection
3. USB connection monitoring
4. Host Computer Watchdog
5. Exposure Duration Detection and Limitation
6.Voltage and Current Safety Control System

US

FCC、 FDA、 UL62368

EU

CE-EMC、CE-LVD、ROHS

Support OS

Windows & Mac OS & web & Linux

Support Software

LaserGRBL/LightBurn

Support Format

jpg/png/gif/ai/pdf/bmp/dxf/gcode/plt/svg

Engraving Material

Medium Density Fiberboard (MDF), Plywood, Pine Wood, Paulownia Wood, Cardboard, Paper, Kraft Paper, Leather, Dark Acrylic, Cobblestones, Ceramics, Coated Metal, Electroplated Metal, Stainless Steel, Glass, Knitted Fabric, Cotton, ABS Plastic, Bamboo, Silicone, Rubber, Ceramics, Marble, Shale, Cement, Bricks, etc.

Cutting Material

Paper, MDF (Medium - Density Fiberboard), plywood, pine wood, paulownia wood, cardboard, corrugated paper, dark acrylic, PVC (Polyvinyl Chloride), knitting, cotton, ABS (Acrylonitrile - Butadiene - Styrene) plastic, felt, leather, bamboo, silica gel

No videos available at the moment

[Tutorial] Installation of Ortur Laser Master 2 S2

OLM2 S2-Installation of LU2-10A

Ortur Laser Master 2 S2- Installation of LU2-10B Laser Module with OUC2.0

Ortur Laser Master 2 S2- Installation of LU2-10A Laser Module with OUC2.0

[Tutorial] How to connect OLM2 to YRC | Stainless Steel Cup Engraving

[Tutorial] How to connect YRR2.0 with Ortur Laser Master 2 S2

ORTUR OLM2 S2 | LU2-10A Laser Module Installation(OUC2.0)

Laser master 2 S2 - Adjusting the Machine

OLM2 S2-Y-axis Synchronous belt adjustment

OLM2 S2-X-axis Synchronous belt adjustment

[Tutorial] How to Replace Motherboard of Ortur Laser Mster 2 S2

[Function Display] Engraving on Stainless Steel Wine Pot with OLM2 S2

[Function Display] How to Cut and Engrave on Paper Cardboard

[Tutorial] Let's DIY your own Thermal Cup!

[Function Display] Engraving on Notebook with OLM2
