Product

ORTUR H20

Product Material

Auminum

Product DIM.

Dimension of whole machine 625*462*272 mm
Top cover size 625*462*92 mm
Main body size 625*462*105 mm
Base Size 625*462*81 mm

Package DIM.

Packing size of whole machine 715*565*475 mm
Packing size of top cover 700*545*135 mm
Package size of main unit 700*545*135 mm
Packing size of main unit + top cover 700*545*150 mm
Packing size of base 700*545*135 mm

N.W.

Net Weight(2W) 14.42 Kg
Net Weight(10W) 19.964 Kg
Net Weight(20W) 21.29 Kg
Net Weight(40W) 21.62 Kg
Cover Net Weight 3.6 Kg
Main Unit Net Weight (2W) 9.14 Kg
Net Weight(10W) 11.714 Kg
Net Weight (20W) 13.04 Kg
Main Unit Net Weight (40W) 13.37 Kg
Chassis Net Weight 1.67 Kg

G.W.

Whole package (2W) 21.14 Kg
Whole Package (10W) 21.795 Kg
Whole Pack (20W) 23.121 Kg
Whole Package (40W) 23.451 Kg
Top Cover Package 4.97 Kg
Main Unit Packaging 11.07 Kg
Main Unit + Cover Pack (2W) 18.5477 Kg
Mainframe + Top Cover Pack (10W) 18.3477 Kg
Mainframe + Top Cover Pack (20W) 19.6737 Kg
Main Unit + Top Cover Package (40W) 20.0037 Kg
Chassis Package 3.28 Kg

Shipping Method

Whole machine shipment

Product Feature

Boxable and boxable split design, upgraded platform with camera

The photoelectric power is related to the laser module supporting the machine.

LR4-2A Power: 80w
Optical Power: 2w
AC/DC Output: 24V 6A

LB4-10A Power: 96w
Optical Power: 10w
AC/DC Output: 24V 4A

LB4-20A Power: 144w
Optical Power: 20w
AC/DC Output: 24V 6A

LB4-40A Power: 216w
Optical Power: 40w
AC/DC Output: 9A

Motor

Step Motor Nema 17 (X38/Y58mm)

Working Speed

20,000mm/min

Working Area

LR4-2A：X420*Y275mm
LB4-10A：X420*Y300mm
LB4-20A：X420*Y300mm
LB4-40A ：X410*Y275mm

Extension Area（Optional）

/

Mainboard

OLM-ESP-H20 V2.2

Support Function

WIFI/APP/USB/TF Card

Security Function

1.Active position protection
2.Tilt motion detection
3.Anti-crash watchdog mechanism
4.Laser irradiation time limit
5.Voltage and current safety control system
6.Emergency stop button
7. Safety door protection
8. Flame detection (with 40W laser)
9. Air pressure detection (with 40W laser)

US

FCC-ID, FDA, IEC/EN 60825-1, CE-EMC (Latest Version), CE-LVD (Latest Version), RED, RoHS, IEC 62368-1, GB 26572-2011

EU

/

Support OS

Android / iOS / Windows / Mac OS / web / Linux

Support Software

LaserGRBL/LightBurn

Support Format

jpg/png/gif/ai/pdf/bmp/dxf/gcode/plt/svg

Engraving Material

Medium Density Fiberboard (MDF), Plywood, Pine Wood, Paulownia Wood, Cardboard, Paper, Kraft Paper, Leather, Dark Acrylic, Cobblestones, Ceramics, Coated Metal, Electroplated Metal, Stainless Steel, Glass, Knitted Fabric, Cotton, ABS Plastic, Bamboo, Silicone, Rubber, Ceramics, Marble, Shale, Cement, Bricks, etc.

Cutting Material

Paper, MDF (Medium - Density Fiberboard), plywood, pine wood, paulownia wood, cardboard, corrugated paper, dark acrylic, PVC (Polyvinyl Chloride), knitting, cotton, ABS (Acrylonitrile - Butadiene - Styrene) plastic, felt, leather, bamboo, silica gel
