Ortur F10 Support

related downloads

All downloads related to F10

1. User Manual

The user manual is an instruction manual that describes the functions, installation and use of the laser engraving machine in detail, allowing users to understand how to use the machine.

2. Laser Module User Manual

The laser module user manual is an instruction manual that details the functions, installation and use of different laser module for the engraving machine.

3. Software Guide

Software Guide

The software guide is to be compatible with more operating systems and devices. Here you can download the software, learn the operation, and obtain parameters.



  • Ortur
  1. Support OS：IOS、Android
  2. Support Machines：OLM3 LE、OLM3、OLM H10、OLM H20、OLM F10、R2
  3. APK Download Link：
  4. User Manual Download Link：Ortur_UserManual_231214.pdf
  • LightBurn
  1. Support OS：Windows、Mac OS、Linux
  2. Support Machines：All Ortur laser engraving machines
  3. Download Link：LightBurn Download link
  • LaserGRBL
    1. Support OS：Windows from XP to Win 11
    2. Support Machines：All Ortur laser engraving machines
    3. Download Link：LaserGRBL Download link

4. Firmware Release

In some circumstances, a firmware update is required to improve the Ortur machine performance or fix discovered issues. In some less common situations, a firmware upgrade might be required to clear issues caused by user error.

  • ESP_F10_227RC4_2411011624
  1. Release Date: 01/11, 2024
  2. Version: V227RC4
  3. Update information:
    • Fixed regular upgrade issues
  4. Note: Oficial Release version
  5. Download Link: ESP_F10_227RC4_2411011624.bin
  • ESP_F10_240815_1103
  1. Release Date: 15/08, 2024
  2. Version:
  3. Update information:
    • Fixed regular upgrade issues
  4. Note: Oficial Release version
  5. Download Link: ESP_F10_240815_1103.bin

  • Specifications

  • Product Promotion

  • Tutorial videos

  • Support Videos

  • Finished video

Product

ORTUR F10

Product Material

Auminum

Product DIM.

574.5×212.5×176.5mm

Package DIM.

625×342×227mm
717×342×227mm（+AirPump）

N.W.

7.6KG (including support assembly)

G.W.

11.5KG

Shipping Method

Whole machine shipment

Product Feature

Automatic feeding, large area engraving and cutting

The photoelectric power is related to the laser module supporting the machine.

LR4-2B Peak Power: 80W
Optical Power: 2w
AC/DC Output: 24V 6A

LU2-10B   Peak Power: 96w
Optical Power: 10w
AC/DC Output: 24V 4A

LU3-20B   Peak Power: 144w
Optical Power: 20w
AC/DC Output: 24V 6A

LU3-40A   Peak Power: 216w
Optical Power: 40w
AC/DC Output: 24V 9A

Motor

Step Motor Nema 17 (X38/Y58mm)

Working Speed

20000mm/min

Working Area

LR4-2A：X420*Y275mm
LB4-10A：X420*Y300mm
LB4-20A：X420*Y300mm
LB4-40A ：X410*Y275mm

Extension Area（Optional）

/

Mainboard

OLM-ESP-F10-V2.9

Support Function

WIFI/APP/USB/TF Card

Security Function

1.Active position protection
2.Tilt motion detection
3.Anti-crash watchdog mechanism
4.Laser irradiation time limit
5.Voltage and current safety control system

US

FCC，FDA，UL62368

EU

IEC/EN 60825-1, CE-EMC (Latest Version), CE-LVD (Latest Version), RED, IEC 62368-1

Support OS

Android / iOS / Windows / Mac OS / web / Linux

Support Software

LaserGRBL/LightBurn

Support Format

jpg/png/gif/ai/pdf/bmp/dxf/gcode/plt/svg

Engraving Material

Medium Density Fiberboard (MDF), Plywood, Pine Wood, Paulownia Wood, Cardboard, Paper, Kraft Paper, Leather, Dark Acrylic, Cobblestones, Ceramics, Coated Metal, Electroplated Metal, Stainless Steel, Glass, Knitted Fabric, Cotton, ABS Plastic, Bamboo, Silicone, Rubber, Ceramics, Marble, Shale, Cement, Bricks, etc.

Cutting Material

Paper, MDF (Medium - Density Fiberboard), plywood, pine wood, paulownia wood, cardboard, corrugated paper, dark acrylic, PVC (Polyvinyl Chloride), knitting, cotton, ABS (Acrylonitrile - Butadiene - Styrene) plastic, felt, leather, bamboo, silica gel
